Silicone Rubber Sorting Machine
  • Silicone Rubber Sorting MachineSilicone Rubber Sorting Machine

Silicone Rubber Sorting Machine

Silicone rubber sorting machine, also known as silicone machine and silicone plastic separator, is a sorting equipment for solid waste broken materials. It uses elasticity and friction to separate silicone, rubber, wood, tape and dust in the plastic mixture. The separation of impurities reduces the frequency of screen changes in the subsequent granulation process and the hollowness, blisters, peeling and delamination of the product during the injection molding process, thereby increasing product value. As the front-end equipment of the electrostatic separator, the silica gel separator can be used alone or in conjunction with the electrostatic separator.

Send Inquiry

Product Description


Application fields of silicone rubber sorting machine

Silicone rubber sorting machine can be widely used in the field of solid waste sorting, and can be used for battery shell materials, steel plant materials, iron plant PP materials, home appliance materials, daily miscellaneous materials, battery shell materials, HDPE crushed materials, PP salt water bottle crushed materials , PC crushed materials, PC/ABS crushed materials, PA crushed materials and other crushed materials that need to be purified and engineering injection molding, etc., the sorting purity reaches more than 98%.

Working principle of silicone rubber sorting machine

Silicone rubber sorting machine is a sorting equipment that separates elastic materials such as silicone, rubber, and plastic. It uses the principle of electrostatic friction and bouncing to produce different parabolas according to the different friction and bouncing forces of different materials such as plastic, silicone, and rubber. Material sorting: silica gel, rubber, sawdust, sponges and light objects contained in plastics are sorted out, with an effective separation rate of 98%. Significantly improve the purity of materials, reduce the frequency of screen changes in the subsequent granulation process, and reduce product hollowness, blisters, peeling and stratification during the injection molding process, and increase product value.

Advantages of silicone rubber sorting machine

(1) Simple operation and cost saving
The silicone rubber sorting machine adopts a master control power distribution cabinet and multiple control buttons to achieve intelligent control. Just put the materials evenly into the equipment to easily complete the separation and sorting. The operation is simple and saves labor costs.

(2) The sorting effect is stable
The silicone rubber sorting machine uses the principle of electrostatic friction and bouncing to generate different parabolas according to the different friction and bouncing forces of plastic, silica gel, and rubber to sort materials, and separate the silica gel, rubber, sawdust, etc. contained in the plastic. The sorting rate of sponges and light objects can reach 98%, effectively avoiding the waste of resources.

(3) Use vertical elevator to load materials
The vertical elevator is a device used to transport materials. Materials are transported through a hopper suspended on a chain, which can quickly lift materials from below to above. The vertical elevator operates stably, feeds materials evenly, and occupies a small area. Can greatly save space.

(4) Variable frequency control
In the variable frequency speed regulation system, the frequency converter is used to control the motor so that the motor runs at the required speed. The frequency conversion speed regulation system has the advantages of soft start, soft braking and smooth speed regulation, which can save energy.

(5) The baffle gap is adjustable
The baffle gap of the silicone rubber separator is adjustable. The baffle gap can be adjusted according to the separation requirements of materials of different sizes to achieve the ideal separation effect. Simple operation and convenient adjustment.

(6) Adopt modular design
The silicone rubber sorting machine is equipped with multiple observation doors, which can be opened at any time to check the operating status of the equipment to facilitate troubleshooting and maintenance.

(7) Strong and durable
The silicone rubber sorting machine uses thickened square tubes as a whole, making the equipment more stable, less likely to deform, and more durable.

(8) Equipment has long service life
The bearings are from international first-line brands, and the motors and reducers are from mainstream Chinese brands. High-quality bearings, motors, reducers, etc. can extend the service life of the equipment, ensure stable operation of the equipment, and save energy costs.

(9) Environmentally friendly and pollution-free
The silicone rubber sorting machine completely adopts a pure physical sorting method. Different materials have different friction and bouncing force, producing different parabolas to separate and sort mixed materials. The purely physical method will not cause pollution to the environment and can at the same time reduce Waste of resources.

Since there are many models of eddy current aluminum-plastic separators, in order to better provide customers with professional technical services, our company can provide corresponding model recommendations according to the different needs of customers.

Silicone rubber sorting machine parameter table
Product number timely production power Dimensions
Two-axis silicone machine 0.8-1 ton 5KW 2160mm*1800mm*3570mm
Three-axis silicone machine 1-1.5 tons 6KW 2380mm*1500mm*3950mm
Four-axis silicone machine 1.5-2 tons 6.5KW 2160mm*1800mm*4370mm

If you purchase a silicone rubber sorting machine, we will provide a full range of technical support and services to make your use worry-free. The following accessories are also included: silicone machine host, motor, cycloidal reducer, power distribution cabinet, Vibrating feeder, vertical elevator, double screw feeding dryer, automatic feeding bin, elevated legs, operation video, etc.
